DUFLA
Plastic dual belt conveyor - DUFLA
Model: dufla, Type: Plastic belt conveyor for wash tunnel
Flat dual plastic conveyor for wash tunnel system.
Easy entry, Flat, Silent, Self-clean, Self-lubricant wash tunnel conveyor.
Description
JUBO plastic belt conveyor system is designed for loading cars in the wash tunnel.
It's so easy you can self load! Glide into the tunnel and put your car onto the belt conveyor, Sit back and prepare for car wash!
No rails! Each one of the belts are wide. No more stress about scratched wheels, alignment issues, or scuffed tires.
Open entrance. flat conveyor so that you will always feel safely loaded before the car wash begins.
JUBO dual belt conveyor is perfect for large vehicles or hand washing / detailing applications. The extra wide conveyor belt makes loading easy and provides extra space for staff members to stand during service multiple cars can be stacked closely on the belt in the same tunnel, maximizing service speed and minimizing space used. Detailing / wash equipment can be stacked down the tunnel along the conveyor, close at hand when the car is carried past. The JUBO WASH TUNNEL DUAL PLASTIC CONVEYOR reduces the probability of vehicle damage and eliminates rollers and other high-maintenance components.
The advantages of belt conveyor systems over traditional chain conveyors include easy loading & unloading, the ability to accept any size vehicle or tire width, no damage to tires, rims or suspension components and higher customer throughputs.
Additionally, the incorporation of a dual belt conveyor system automatically future-proofs a tunnel against any problems associated with automatic braking systems
Advantages
- Easy entry
- Flat
- Silent
- Self-clean
- Self-lubricant
- Heavy-loading
- Flexibility
- Safety
- High Torque
Specifications
| Electricity and power supply | 3PHASE 380V 50HZ 4kW, 8A 3PHASE 220V 60HZ 4kW, 13A |
|---|---|
| Electrical system | French Schneider |
| Material | Hot dipped galvanized steel, Stainless steel 304 |
| Control system | VFD, electric motor and gear box |
| Conveyor speed | 0 - 10000mm/min 0 - 395inch/min |
| Belt material | Plastic DuPont |
| Belt width | 600mm = 24inch |
| Belt length | 12000mm = 40ft 24000mm = 80ft 36000mm = 120ft 48768mm = 160ft 60960mm = 200ft |
| Belt quantity | 1 single 2 dual |
| Stud pusher distance | 600mm = 24inch |
| Sprocket | Nylon (pa6) drive sprocket |
| Glide plates | Stainless steel 304 |
| Shaft | Zinc-nickel coated drive-shafts and couplings |
| Pit Length | Vary along with belt length |
| Pit width | 4600mm for drive area 2800 for belt area |
| Pit depth | 800 - 1200mm 30 – 50inch |
| Vehicle tyres lateral distance | Min inner width 1100mm = 45inch Max outer width 2300mm = 90inch |
Deployment
Deployed for outdoor wash stations, several self-serve wash bays and single automatic car wash system will be a good idea to work together. Steel frame is necessary to support the components.
Application
- Mini
- Sedan
- SUV
- MPV
- Pickup-Truck
