ROFLO

Wash Bus&Truck System - JUBO ROFLO

Model: roflo, Type: Gantry roll-over bus wash system

ROLL-OVER TRUCK WASH SYSTEM

Commercial Vans,Truck, Bus, Gabage truck Wash system made by JUBO China
Gantry type, Roll-over 3-brushes gantry type

Bus wash - truck wash system with 3brushes ROFLO JUBO

Specifications

Electricity and power supply3PHASE 380V 50HZ 45kW
Electrical systemFrench Schneider
Min installation dimensionsL18000 x W4500 x H5500mm
Max washing vehicle dimensionsL14000, x W3400 x H4200mm
MaterialHot dipped galvanized steel, Stainless steel 304
PumpCentrifugal pump 3kW
Water pressure5~20Bar, 140L/min adjustable
Wash speed5-10minutes/vehicle, adjustable
Chemical consumption0.02~0.08L/ vehicle, adjustable

Gantry Type

Combined with functions of HP Chassis wash & HP Rinse arc, Top brush, Vertical brushes, Lava-Foam(optional), Tri-color foam(optional), Soap(optional), Hot Wax(optional), Spotless(optional), Dryer(optional), Dryer(optional), etc.

Deployment

Deployed for coach center, bus parking lot, truck parking lot etc.

Application

  1. Vans
  2. Bus
  3. Pickup-Truck
  4. Fleet
  5. Trucks and equipment
  6. School buses
  7. Tractor-trailers
  8. Military vehicles
  9. Semi-trucks
  10. Garbage trucks
  11. Oil mining vehicles

Catalog

  • JUBO CAR WASH CATALOG
